Light Source
Lamp : Multichip 800W Led
7Color Temperature : 2700K-6200K
Source life expectancy : 50.000 hours
Optcs
Lens Diameter : 150mm
Spot : 5°～ 50°
Focus : Motorized Focus
Zoom : Motorized Zoom
Color System
Colour mixing: CMY colour system on 2x5 Color Disc
Colour wheel: CMY + CRI + CTO ‘’ 2700K-6200K ‘’
Body
Material : Magnesium - Aliminum Alloy
Body Color : Black
Transport : Two side handles
Device Locking PAN and TILT : Yes
Head Movement
Pan : 540º 8/16Bit
Tilt : 360º 8/16Bit
Pan/Tilt Resolution:
Packng
Professional 90 Degree Clamp : Including
Power Cable : TrueCon with Cable
Signal : Male / Female Connector ‘’ 3 pin & 5 Pin & Art-NET
‘optional’
Control
Protocols : DMX512 ‘’ Built-in Program, DMX, Master Slave ‘’
Short Mode : 42 Channels
Standart Mode : 42/43/49/50/51 Channels
Display : LCD Display
Dimmer / Strobe
Dimmer : 0-100% Electronic Dimmer
Strobe at variable speeds (15 F.P.S at maximum)
Dynamc Effects
Profile Spot : Yes ‘’ 4 Plates. After cut, the pattern can rotation 180°
Fixed Gobo : 9 fixed gobos + open & 7 x Rotating Gobo + Open
Effect : High speed shake effect
Strobe Effect : Mechanical shutter ‘’ optional ‘ and adjustable speed
strobe effect
Frost : Motorized
Dimmer : Mechanical dimmer
PRISM
Prism 1 : 4-face Rotating prism
Frost : Motorized
Physcal
IP Rating : IP 65
Net Weight kg. : 35Kg.
Dimension : 357mmx256mmx742mm
Cooling : Forced Air With Fan
Clamp : Omega Brackets 90 Degree Professional Clamp ‘’Optional‘’
Connectors : TrueCon + Signal : 3 pin & 5 Pin
Electrcal
Main Powersupply : 100V-240V 50/60Hz
Input Power : 950W@230V
Power Factor : PF>0.90
